Standard C528 / 520 Service Manual
Search
| Transmitter Type | Solid State |
| Frequency Range | 144 - 148, 430 - 440 Mhz (Capable of extended RX & TX with software key) |
| Memory Channels | 10 VHF and 10 UHF |
| Modes | FM |
| RF Power | 350mW Low, 2.5 Watts Mid, and 5 Watts High |
| RF Impedance | 50 Ohm |
| Receiver Type | Solid State, Double - Dual Conversion Superheterodyne |
| Frequency Range | 144 - 148, 430 - 440 Mhz (Capable of extended RX & TX with software key) |
| Memory Channels | 10 VHF and 10 UHF |
| Sensitivity | 0.25uV for 12dB SINAD or better |
| Download Description | File Name | File Size |
| Service Manual in (.pdf format) | Standard C528 Service Manual.pdf | 30.8 Mbytes |
Background
The Standard C-528 Transceiver was released in Australia in the mid 1980's and was a very innovative and popular twin band 2m and 70cm hand-held transceiver and many were sold in VK.
The C-528 appears identical to the Standard C-520 and there are only minor electrical differences between them, as can be seen in the manual.
